Synthetic Resin Roof Tile Extrusion Machine / Plastic Roofing Sheet Making Machine Price In China

synthetic resin tile machine china manufacturer supply                                                                                                                                              synthetic resin tile machine china manufacturer suppy

Synthetic Resin Roof Tile Extrusion Machine / Plastic Roofing Sheet Making Machine Price In China

The roof panel machine consists of conical twin screw extruder, hanger-style flat die, size forming mould, high-efficiency vacuum pump, hauling-off unit, pneumatic cutter and other auxiliary equipment.


Quick Detail:
The pvc roofing sheet forming machine is mechanotronics, with the advantages of:
1. Good performance
2. High quality
3. Reasonable and compact


ExtruderSJ50/30 +SJZS65/SJZS80/156/SJZS92/188
Mold width1300mm
Shaping width800*1300mm
Haul off roller quantityone pair the upper and lower part
Cutting modePneumatic cutting
Max output350kg/h
Drive motor55kw+15kw
Machine weight22000kg
Machine Size17*2.5*2.2m
specification of the roof sheet(Can be customized according to design)
Width840/1130mm
shapeRound/trapezoidal
thickness0.8~3mm

Description:
The pvc roofing sheet forming machine by following parts:
1, Extruder,
2, Extrusion mould,
3, Calibration system,
4, Haul-off machine,
5, Cutter and stacker.


Applications:
The pvc roofing sheet machine is mainly used in the production of plastic roofing tile,which is widely used in:
Roofing for workshop, warehouse, market;
Roofing for parking lot, corridor, passage, balcony;
Clapboard of the road and etc.


Competitive Advantage:
The roof panel machine consists of conical twin screw extruder, hanger-style flat die, size forming mould, high-efficiency vacuum pump, hauling-off unit, pneumatic cutter and other auxiliary equipment.


Machine list:
No.MachineQty.
1Screw loader for extruder1setMain tile extrusion line

Ridge tile forming
2Conical twin-screw extruder(PVC)1set
3Vacuum loader and drying hopper1set
4Single screw extruder(ASA)1set
5Extrusion mould and distributor1set
6Calibration mould and trimming device1set
7Haul off unit1set
8Cutter1set
9Stacker1set
10Ridge tile Oven1set
11Ridge tile Forming machine and mould1set




12Screw loader for Mixer1setAuxiliary equipment
13Mixer unit1set
14Crusher1set
15Pulverizer1set

Work flow:
Mixer for bottom layer(PVC powder, CaCO3, CPE, PE-WAX, Stearic acid, Compound stabilizer, ACR, paraffin)

Extrusion process: Conical twin-screw extruder for bottom layer-Single screw extruder for Surface layer(ASA)-Mould-surface embossing(Optional)-Forming machine-Haul-off-cutter-stacker –Main tile

Oven-Ridge tile machine and mould-1set Ridge tile

Crusher(waste material)-Pulverizer—Reuse again for extrusion line

Product installation method:
Metal supporting
Tool: screw, presser, Pressing cap, rubber ring, gasket
